Zynex ZX-3M-1020 10kW Hybrid Solar Inverter – 3 MPPT

Description

The Zynex ZX-3M-1020 10kW Hybrid Solar Inverter is designed for larger residential and commercial solar power systems, combining high PV input capacity, flexible battery support, and intelligent hybrid operation. With a maximum PV array capacity of 20kW and 3 independent MPPT trackers, it supports flexible solar array configurations while allowing up to 200% PV oversizing.

Each MPPT supports up to 20A input current, making the inverter suitable for modern high-power and bifacial solar modules. Its 40–60V battery voltage range supports both Lithium (LiFePO₄) and lead-acid batteries, with up to 10kW charge/discharge power and 210A maximum current.

The ZX-3M-1020 also features UPS-level switching below 10ms, supporting fast backup power during grid outages. Its scalable design can support expansion up to 30kW, while multi-source black start allows PV, battery, and generator sources to be integrated for system restart capability.

With an IP66 protection rating, the Zynex ZX-3M-1020 is designed for both indoor and outdoor installation.

Key Features

• 10kW rated AC output
• Up to 20kW maximum PV array power
• 3 independent MPPT trackers
• 20A maximum input current per MPPT
• Up to 200% PV oversizing
• 550V maximum PV input voltage
• 40–60V battery voltage range
• Supports Lithium (LiFePO₄) and lead-acid batteries
• 10kW maximum charge/discharge power
• 210A maximum charge/discharge current
• UPS-level switching time of <10ms
• Expandable up to 30kW
• Multi-source black start
• IP66 protection rating
• Suitable for indoor and outdoor installation
• Up to 97.6% maximum efficiency
