Zynex ZX-3M-0816 8kW Hybrid Solar Inverter – 3 MPPT

The Zynex ZX-3M-0816 8kW Hybrid Solar Inverter is designed for residential and commercial solar energy systems requiring flexible PV input, battery storage, and hybrid grid/off-grid operation. With a 16kW maximum PV array capacity and 3 independent MPPT trackers, it supports flexible solar array configurations and efficient energy harvesting.

Each MPPT supports up to 20A input current, making the inverter suitable for high-power and bifacial solar modules. It supports up to 200% PV oversizing, allowing a larger PV array to maximize solar energy generation.

The ZX-3M-0816 supports 40–60V battery systems and is compatible with Lithium (LiFePO₄) and lead-acid batteries. It provides up to 8kW charge/discharge power with a maximum charge/discharge current of 190A.

With UPS-level switching below 10ms, the inverter is designed to provide fast backup power during grid outages. It also supports multi-source black start using PV, battery, and generator sources and can be expanded up to 30kW for future system requirements.

Its IP66 protection rating makes it suitable for both indoor and outdoor installations.

Key Features

• 8kW rated AC output
• Up to 16kW maximum PV array power
• 3 independent MPPT trackers
• 20A maximum input current per MPPT
• Up to 200% PV oversizing
• 550V maximum PV input voltage
• 40–60V battery voltage range
• Supports Lithium (LiFePO₄) and lead-acid batteries
• 8kW maximum charge/discharge power
• 190A maximum charge/discharge current
• UPS-level switching time of <10ms
• Expandable up to 30kW
• Multi-source black start
• IP66 protection rating
• Suitable for indoor and outdoor installation
• Up to 97.6% maximum efficiency

Specifications
